"DeltaBucker Deluxe" 3-string Maple Cigar Box Guitar Humbucker Pickup pre-wired with Volume & Tone - No Soldering
- SKU:
- 54-063-01
- UPC:
- 602589223230
Description
Foundry Tone Pickups by C. B. Gitty introduces
Tone that's straight out of a juke joint.
Primal and unrefined... without the hum.
DELUXE VERSION! Includes fully pre-wired harness with volume & tone pots and 1/4" jack.
Summary:
Fully-potted cigar box guitar humbuckers, gnashing out a powerfully hot 9.22 k through Alnico magnets. DeltaBuckers deliver gloriously trashy tones for deep electric blues. Yeah, you read that right: trashy. Essential for slide guitarists looking for the elusive tones that fall between "Chicago Hound Dog" and "North Mississippi RL."
No wiring. No soldering. All Foundry Tone DeltaBuckers are prewired. Just shove 'em in your next masterpiece and plug it into an amp. It's as simple as that.
DeltaBuckers feature engraved wooden bobbins, and come pre-wired to a mono output jack with a 15-inch shielded lead to the volume pot, 4 inch lead to the tone control and a 9 inch lead to the input jack. If there are any troubles with feedback, there is a white wire leading from the volume pot that can be soldered to a metal bridge or tailpiece. These pickups come pre-installed with a Maple pickup ring, making installation even easier!
Chrome mounting screws for the pickup ring are included.
Specifications:
Magnets: Alnico 5
Impedance: 9.22 k ohms
Volume & Tone Potentiomers: 250k
Capacitor Value: .047
Size Specs:
Pole spacing: ~1/2" center to center (~13mm)
Total Pole Spread (center to center): 1" (~27mm)
Pickup Height: 1 3/8"
Pickup Height with Ring: 1 13/16" (~46mm)
Pickup Width: 1 3/4" (~mm)
Pickup Width with Ring: 2 7/8" (~mm)
Thickness: 23/32" (~18mm)
